DNSreport for amazon.com

mail iconEmail link to results
Generated by www.DNSreport.com at 18:04:23 GMT on 05 May 2009.

CategoryStatusTest NameInformation
Parent PASSMissing Direct Parent checkOK. Your direct parent zone exists, which is good. Some domains (usually third or fourth level domains, such as example.co.us) do not have a direct parent zone ('co.us' in this example), which is legal but can cause confusion.
INFONS records at parent serversYour NS records at the parent servers are:

udns1.ultradns.net. [204.69.234.1] [TTL=172800] [US]
udns2.ultradns.net. [204.74.101.1] [TTL=172800] [US]
[These were obtained from k.gtld-servers.net]
PASSParent nameservers have your nameservers listedOK. When someone uses DNS to look up your domain, the first step (if it doesn't already know about your domain) is to go to the parent servers. If you aren't listed there, you can't be found. But you are listed there.
PASSGlue at parent nameserversOK. The parent servers have glue for your nameservers. That means they send out the IP address of your nameservers, as well as their host names.
PASSDNS servers have A recordsOK. All your DNS servers either have A records at the zone parent servers, or do not need them (if the DNS servers are on other TLDs). A records are required for your hostnames to ensure that other DNS servers can reach your DNS servers. Note that there will be problems if your DNS servers do not have these same A records.
NS INFONS records at your nameserversYour NS records at your nameservers are:

pdns5.ultradns.info. [204.74.114.1] [TTL=86400]
pdns4.ultradns.org. [199.7.69.1] [TTL=86400]
pdns3.ultradns.org. [199.7.68.1] [TTL=86400]
pdns2.ultradns.net. [204.74.109.1] [TTL=86400]
pdns1.ultradns.net. [204.74.108.1] [TTL=86400]
pdns6.ultradns.co.uk. [204.74.115.1] [TTL=86400]
PASSOpen DNS serversOK. Your DNS servers do not announce that they are open DNS servers. Although there is a slight chance that they really are open DNS servers, this is very unlikely. Open DNS servers increase the chances that of cache poisoning, can degrade performance of your DNS, and can cause your DNS servers to be used in an attack (so it is good that your DNS servers do not appear to be open DNS servers).
PASSMismatched glueOK. The DNS report did not detect any discrepancies between the glue provided by the parent servers and that provided by your authoritative DNS servers.
PASSNo NS A records at nameserversOK. Your nameservers do include corresponding A records when asked for your NS records. This ensures that your DNS servers know the A records corresponding to all your NS records.
PASSAll nameservers report identical NS recordsOK. The NS records at all your nameservers are identical.
PASSAll nameservers respondOK. All of your nameservers listed at the parent nameservers responded.
PASSNameserver name validityOK. All of the NS records that your nameservers report seem valid (no IPs or partial domain names).
PASSNumber of nameserversOK. You have 2 nameservers. You must have at least 2 nameservers (RFC2182 section 5 recommends at least 3 nameservers), and preferably no more than 7.
PASSLame nameserversOK. All the nameservers listed at the parent servers answer authoritatively for your domain.
FAILMissing (stealth) nameserversFAIL: You have one or more missing (stealth) nameservers. The following nameserver(s) are listed (at your nameservers) as nameservers for your domain, but are not listed at the parent nameservers (therefore, they may or may not get used, depending on whether your DNS servers return them in the authority section for other requests, per RFC2181 5.4.1). You need to make sure that these stealth nameservers are working; if they are not responding, you may have serious problems! The DNSreport will not query these servers, so you need to be very careful that they are working properly.

pdns5.ultradns.info.
pdns4.ultradns.org.
pdns3.ultradns.org.
pdns2.ultradns.net.
pdns1.ultradns.net.
pdns6.ultradns.co.uk.
This is listed as an ERROR because there are some cases where nasty problems can occur (if the TTLs vary from the NS records at the root servers and the NS records point to your own domain, for example).
FAILMissing nameservers 2ERROR: One or more of the nameservers listed at the parent servers are not listed as NS records at your nameservers. The problem NS records are:
udns1.ultradns.net.
udns2.ultradns.net.
PASSNo CNAMEs for domainOK. There are no CNAMEs for amazon.com. RFC1912 2.4 and RFC2181 10.3 state that there should be no CNAMEs if an NS (or any other) record is present.
PASSNo NSs with CNAMEsOK. There are no CNAMEs for your NS records. RFC1912 2.4 and RFC2181 10.3 state that there should be no CNAMEs if an NS (or any other) record is present.
PASSNameservers on separate class C'sOK. You have nameservers on different Class C (technically, /24) IP ranges. You must have nameservers at geographically and topologically dispersed locations. RFC2182 3.1 goes into more detail about secondary nameserver location.
PASSAll NS IPs publicOK. All of your NS records appear to use public IPs. If there were any private IPs, they would not be reachable, causing DNS delays.
PASSTCP AllowedOK. All your DNS servers allow TCP connections. Although rarely used, TCP connections are occasionally used instead of UDP connections. When firewalls block the TCP DNS connections, it can cause hard-to-diagnose problems.
INFONameservers versions[For security reasons, this test is restricted to customers.]
FAILStealth NS record leakageYour DNS servers leak stealth information in non-NS requests:

Stealth nameservers are leaked [pdns6.ultradns.co.uk.]!
Stealth nameservers are leaked [pdns5.ultradns.info.]!
Stealth nameservers are leaked [pdns4.ultradns.org.]!
Stealth nameservers are leaked [pdns3.ultradns.org.]!
Stealth nameservers are leaked [pdns2.ultradns.net.]!
Stealth nameservers are leaked [pdns1.ultradns.net.]!

This can cause some serious problems (especially if there is a TTL discrepancy). If you must have stealth NS records (NS records listed at the authoritative DNS servers, but not the parent DNS servers), you should make sure that your DNS server does not leak the stealth NS records in response to other queries.
SOA INFOSOA recordYour SOA record [TTL=7200] is:

Primary nameserver: udns1.ultradns.net.
Hostmaster E-mail address: hostmaster.amazon.com.
Serial #: 2009050102
Refresh: 28800
Retry: 3600
Expire: 1209600
Default TTL: 3600
PASSNS agreement on SOA Serial #OK. All your nameservers agree that your SOA serial number is 2009050102. That means that all your nameservers are using the same data (unless you have different sets of data with the same serial number, which would be very bad)! Note that the DNSreport only checks the NS records listed at the parent servers (not any stealth servers).
PASSSOA MNAME CheckOK. Your SOA (Start of Authority) record states that your master (primary) name server is: udns1.ultradns.net.. That server is listed at the parent servers, which is correct.

PASSSOA RNAME CheckOK. Your SOA (Start of Authority) record states that your DNS contact E-mail address is: hostmaster@amazon.com. (techie note: we have changed the initial '.' to an '@' for display purposes).
PASSSOA Serial NumberOK. Your SOA serial number is: 2009050102. This appears to be in the recommended format of YYYYMMDDnn, where 'nn' is the revision. So this indicates that your DNS was last updated on 01 May 2009 (and was revision #2). This number must be incremented every time you make a DNS change.
PASSSOA REFRESH valueOK. Your SOA REFRESH interval is : 28800 seconds. This seems normal (about 3600-7200 seconds is good if not using DNS NOTIFY; RFC1912 2.2 recommends a value between 1200 to 43200 seconds (20 minutes to 12 hours)). This value determines how often secondary/slave nameservers check with the master for updates.
PASSSOA RETRY valueOK. Your SOA RETRY interval is : 3600 seconds. This seems normal (about 120-7200 seconds is good). The retry value is the amount of time your secondary/slave nameservers will wait to contact the master nameserver again if the last attempt failed.
PASSSOA EXPIRE valueOK. Your SOA EXPIRE time: 1209600 seconds. This seems normal (about 1209600 to 2419200 seconds (2-4 weeks) is good). RFC1912 suggests 2-4 weeks. This is how long a secondary/slave nameserver will wait before considering its DNS data stale if it can't reach the primary nameserver.
PASSSOA MINIMUM TTL valueOK. Your SOA MINIMUM TTL is: 3600 seconds. This seems normal (about 3,600 to 86400 seconds or 1-24 hours is good). RFC2308 suggests a value of 1-3 hours. This value used to determine the default (technically, minimum) TTL (time-to-live) for DNS entries, but now is used for negative caching.
MX INFOMX RecordYour 3 MX records are:

10 smtp-fw-9101.amazon.com. [TTL=7200] IP=207.171.184.25 [TTL=7200] [US]
10 smtp-fw-4101.amazon.com. [TTL=7200] IP=72.21.198.25 [TTL=7200] [US]
10 smtp-fw-2101.amazon.com. [TTL=7200] IP=72.21.196.25 [TTL=86400] [US]
PASSLow port testOK. Our local DNS server that uses a low port number can get your MX record. Some DNS servers are behind firewalls that block low port numbers. This does not guarantee that your DNS server does not block low ports (this specific lookup must be cached), but is a good indication that it does not.
PASSInvalid charactersOK. All of your MX records appear to use valid hostnames, without any invalid characters.
PASSAll MX IPs publicOK. All of your MX records appear to use public IPs. If there were any private IPs, they would not be reachable, causing slight mail delays, extra resource usage, and possibly bounced mail.
PASSMX records are not CNAMEsOK. Looking up your MX record did not just return a CNAME. If an MX record query returns a CNAME, extra processing is required, and some mail servers may not be able to handle it.
PASSMX A lookups have no CNAMEsOK. There appear to be no CNAMEs returned for A records lookups from your MX records (CNAMEs are prohibited in MX records, according to RFC974, RFC1034 3.6.2, RFC1912 2.4, and RFC2181 10.3).
PASSMX is host name, not IPOK. All of your MX records are host names (as opposed to IP addresses, which are not allowed in MX records).
PASSMultiple MX recordsOK. You have multiple MX records. This means that if one is down or unreachable, the other(s) will be able to accept mail for you.
PASSDiffering MX-A recordsOK. I did not detect differing IPs for your MX records (this would happen if your DNS servers return different IPs than the DNS servers that are authoritative for the hostname in your MX records).
PASSDuplicate MX recordsOK. You do not have any duplicate MX records (pointing to the same IP). Although technically valid, duplicate MX records can cause a lot of confusion, and waste resources.
PASSReverse DNS entries for MX recordsOK. The IPs of all of your mail server(s) have reverse DNS (PTR) entries. RFC1912 2.1 says you should have a reverse DNS for all your mail servers. It is strongly urged that you have them, as many mailservers will not accept mail from mailservers with no reverse DNS entry. Note that this information is cached, so if you changed it recently, it will not be reflected here (see the www.DNSstuff.com Reverse DNS Tool for the current data). The reverse DNS entries are:

25.184.171.207.in-addr.arpa smtp-fw-9101.amazon.com. [TTL=769]
25.198.21.72.in-addr.arpa smtp-fw-4101.amazon.com. [TTL=16842]
25.196.21.72.in-addr.arpa smtp-fw-2101.amazon.com. [TTL=16842]
Mail PASSConnect to mail serversOK: I was able to connect to all of your mailservers.
PASSMail server host name in greetingOK: All of your mailservers have their host name in the greeting:

smtp-fw-4101.amazon.com:<br />    220 smtp-fw-4101.amazon.com ESMTP <br />smtp-fw-2101.amazon.com:<br />    220 smtp-fw-2101.amazon.com ESMTP <br />smtp-fw-9101.amazon.com:<br />    220 smtp-fw-9101.amazon.com ESMTP <br />
PASSAcceptance of NULL <> senderOK: All of your mailservers accept mail from "<>". You are required (RFC1123 5.2.9) to receive this type of mail (which includes reject/bounce messages and return receipts).
PASSAcceptance of postmaster addressOK: All of your mailservers accept mail to postmaster@amazon.com (as required by RFC822 6.3, RFC1123 5.2.7, and RFC2821 4.5.1).
PASSAcceptance of abuse addressOK: All of your mailservers accept mail to abuse@amazon.com.
INFOAcceptance of domain literalsWARNING: One or more of your mailservers does not accept mail in the domain literal format (user@[0.0.0.0]). Mailservers are technically required RFC1123 5.2.17 to accept mail to domain literals for any of its IP addresses. Not accepting domain literals can make it more difficult to test your mailserver, and can prevent you from receiving E-mail from people reporting problems with your mailserver. However, it is unlikely that any problems will occur if the domain literals are not accepted (mailservers at many common large domains have this problem).

smtp-fw-4101.amazon.com's postmaster@[72.21.198.25] response:<br /> >>> RCPT TO:<postmaster@[72.21.198.25]><br /> <<< 550 #5.1.0 Address rejected. <br /> smtp-fw-2101.amazon.com's postmaster@[72.21.196.25] response:<br /> >>> RCPT TO:<postmaster@[72.21.196.25]><br /> <<< 550 #5.1.0 Address rejected. <br /> smtp-fw-9101.amazon.com's postmaster@[207.171.184.25] response:<br /> >>> RCPT TO:<postmaster@[207.171.184.25]><br /> <<< 550 #5.1.0 Address rejected. <br />
PASSOpen relay testOK: All of your mailservers appear to be closed to relaying. This is not a thorough check, you can get a thorough one here.

smtp-fw-4101.amazon.com OK: 550 #5.1.0 Address rejected. <br />smtp-fw-2101.amazon.com OK: 550 #5.1.0 Address rejected. <br />smtp-fw-9101.amazon.com OK: 550 #5.1.0 Address rejected. <br />
PASSSPF recordYou have an SPF record. This is very good, as it will help prevent spammers from abusing your domain. Your SPF record (I don't check to see if it is well designed!) is:
"v=spf1 ip4:207.171.160.0/19 ip4:87.238.80.0/21 ip4:72.21.193.0/24 ip4:72.21.196.0/22 ip4:72.21.208.0/24 ip4:72.21.205.0/24 ip4:72.21.209.0/24 ip4:194.154.193.200/28 ip4:194.7.41.152/28 ip4:212.123.28.40/32 ip4:203.81.17.0/24 ~all" [TTL=7200]
WWW INFOWWW RecordYou have one or more A records for www.amazon.com. I can't test further, however, since www.amazon.com is in its own zone.


Legend:
  • UPDATE NOTICE November 2007:
    We have made the decision to remove the Single Point of Failure test included in DNSreport. This test was developed and enhanced over the past five years along with our other tools. The initial design of the Single Point of Failure test depended on the typical connectivity profiles prevalent at the time. As connectivity has become more robust the methodology employed makes less sense and creates more false positives. Our development team is working on an enhanced Single Point of Failure test for a future release.
  • Rows with a FAIL indicate a problem that in most cases really should be fixed.
  • Rows with a WARN indicate a possible minor problem, which often is not worth pursuing.
  • Note that all information is accessed in real-time (except where noted), so this is the freshest information about your domain.
  • Note that automated usage is not tolerated without the purchase of an Automated Usage plan; please only view the DNS report directly with your web browser.
